4 digits 9999 count & 3-5/6 digits 6000count
■Maximum DC/AC voltage measurement resolution 0.01mV
■Dual Display shows voltage/current and its frequency, and
AC components and DC components of voltage/current
■High speed bar graph
■Frequency measurement (AC sine wave only)
■Logic frequency measurement, duty cycle measurement
■Data hold, Range hold
■Relative value
■Auto power saving mode (30min.) (cancelable)
■Optical Link USB interface (optional)
Display : numeral display 9999 & 6000, bar graph 41 segments
Sampling rate : 5 times/sec., 60 times/sec. for bar graph
Battery life : Approx. 60h (manganese battery) at DCV range
Download this product's manualDownload this product's catalog
Software : PC Link7
Optical PC link cable : KB-USB7
Clamp probe : CL-20D, CL-22AD, CL33DC
Temperature probe : T-300PC (PC Link software is necessary.)
K type adapter : K-AD
Test lead : TL-21M, TLF-120
Carrying case : C-PC7
Clip adapter : CL-13a, CL-14,CL-15a, CL-DG3a, TL-9IC
